KD450T
1 / 1
KD450T - thumbnail 1

KD450T

Type: Top TypeBrand: KD

The top-mounted breaker is lighter in overall weight, making it easier to position during operations. Its easy-control and positioning features make excavation work more convenient, while the absence of side weight reduces chisel breakage rates. Parts install quickly and easily, providing a longer operation range for distance working conditions and delivering more power due to the vertical body design.

Request a Quote

PRODUCT SPECIFICATIONS

Technical details and available options

Suitable Excavator(Min)(ton)

6.0

Suitable Excavator(Max)(ton)

9.0

Suitable Excavator(Suitable)(ton)

7.0

Tool(Moil Type)(Weight)(kg)

25.0

Tool(Moil Type)(Diameter)(mm)

75.0

Operating Weight(Tool + M/C)(kg)

380.0

Operating Weight(Tool + M/C)(lb)

838.0

Main Body Weight(kg)

192.0

Operating Pressure(Breaker)(bar)

100~140

Operating Pressure(Breaker)(psi)

1,450~2,030

Setting Pressure(Machine)(bar)

180.0

Setting Pressure(Machine)(psi)

2610.0

Impact Rate(bpm)

475~950

Back Head Pressure(N2-Gas)(bar/psi)

16/232

Required Oil Flow(l/min)

40~80

Required Oil Flow(g/min)

10.5~21.1

Weight(kg)

504.0

Nitrogen Level/Pressure (kg/cm²)

14-16

Pin Diameter (Ø

60.0

PRODUCT DETAILS

Comprehensive information about this product

The top-mounted breaker maximizes the advantages of vertical installation, making it ideal for sites that require both precision and efficiency. Its optimized weight enables quick and easy equipment positioning, significantly improving work speed at sites requiring continuous operation. Equipped with an intuitive control system, it allows both experienced operators and beginners to adapt quickly. The most notable feature is its design without side load, which dramatically extends chisel lifes...
